Product Overview
The Tank 900 is a green crawler-type cable conveyor featuring dual-mode operation (conveyor/crawler vehicle) with 60V incremental generator power. Designed for complex terrain, it combines exceptional mobility with powerful cable laying capabilities.
Technical Parameter
| Model | Tank 900 |
| Power System | 60V Incremental Generator (4KW) |
| Operation Modes | Conveyor/Crawler Vehicle (switchable) |
| Control Methods | Panel + Wireless Remote |
| Conveying Speed | 4-26m/min (4-gear + stepless) |
| Pulling Force | 6000N |
| Cable Diameter | 2-24cm |
| Fuel Capacity | 5L |
| Dimensions | 126×80×100cm |
| Weight | 430kg |
| Engine Power | 5.5HP |
Features & Advantages
Core Features
Dual Control System
Independent conveyor/crawler operation
4-Gear Precision
Dual-mode speed adjustment with stepless fine-tuning
All-Terrain Mobility
Crawler design for slopes and rough terrain
High-Capacity Power
4KW generator with 5L fuel tank
Dual Control Methods
Panel interface + remote operation
Technical Advantages
Slope Performance
5.5HP engine delivers superior climbing force
Flexible Adaptation
Handles complex working conditions
Synchronized Control
4-gear coordination between walking/conveying
Heavy-Duty Capacity
6000N pulling force for large cables (up to 24cm)
Applications
- Mountainous/hilly cable projects
- Underground pipeline installations
- Power transmission line construction
- Telecommunication infrastructure deployment
Important Notes
- Parameters may vary with cable conditions (e.g., slippage) and environment
- Product appearance may differ slightly from images
- Specifications subject to change without notice
