Power Arrow 4 Capstan Winch

Model
Power Arrow 4
Power Supply
AC380V
Weight
170kg
Engineering Reliable Power Solutions

    Product Overview

    The Power Arrow 4 is an industrial-grade electric motor grinder featuring a blue motor unit with green control box on a green base. Designed for demanding cable operations, it delivers 40KN pulling force with intelligent stepless speed control, making it ideal for power transmission and telecommunication projects.

    Technical Parameter

    Model Power Arrow 4
    Max Pulling Force 40KN
    Speed Range 0-20m/min (stepless adjustment)
    Power 5.5KW premium copper-core motor
    Power Supply AC380V
    Control Methods Control panel + remote control
    Safety Feature Automatic power-off braking
    Dimensions 115×30×40cm
    Weight 170kg

    Features & Advantages

    Applications

    • High-voltage power line construction
    • Telecommunication cable deployment
    • Industrial cable pulling operations
    01
    02
    03
    04
    05
    06
    07

    Power Arrow 4 Capstan Winch: FAQ

    What power supply does Power Arrow 4 use?

    The specification lists a 5.5kW motor and AC380V supply.

    What are its pulling force and speed?

    Maximum pulling force is 40kN, with stepless speed adjustment over 0–20 m/min.

    Which controls are available?

    The listed controls are a control panel and remote control. Confirm the supplied configuration and operating instructions.

    How do I request a quotation or spare parts?

    Send the model, cable or load details, required configuration, quantity and destination. For parts, include the machine identification and component photos.
