Product Overview
The Capstan winch Torque Master 5 Diesel version is a heavy-duty cable pulling machine featuring a distinctive teal body with black/white engine components. Designed for challenging environments, it delivers 50KN pulling force through reliable shaft transmission, making it ideal for mountainous and remote construction projects.
Technical Parameter
| Model | Capstan winch Torque Master 5 Diesel version |
| Power Options | Gasoline/Diesel (selectable) |
| Rated Traction Force | 50KN |
| Dimensions | 110×58×58cm |
| Weight | 157kg |
| Transmission | High-strength shaft coupling |
Gear Performance
• Forward Gear 1: 50KN at 4.5m/min
• Forward Gear 2: 26KN at 8.5m/min
• Forward Gear 3: 20KN at 11m/min
• Forward Gear 4: 10KN at 23m/min
• Reverse Gear 1: 3.5m/min
• Reverse Gear 2: 9m/min
Features & Advantages
Core Features
Dual Fuel System
Choose between gasoline or diesel power
4+2 Gear System
Precise speed and force control
Heavy-Duty Coupling
Reinforced shaft transmission
High Torque Output
Ensures operational safety
Field-Ready Design
Rugged construction for tough environments
Technical Advantages
50KN Maximum Force
Handles extreme pulling demands
Variable Speed Control
4 forward + 2 reverse gears
Reliable Transmission
Shaft-driven power delivery
All-Terrain Capability
Performs in remote locations
Applications
- Mountainous cable installation
- Wild terrain construction
- Power line maintenance
- Telecommunication projects







Capstan winch Torque Master 5 Diesel version: FAQ
What is the rated traction force?
The Torque Master 5 Diesel version lists 50kN rated traction force.
Which power version should I order?
The specification lists selectable gasoline or diesel power. State the required engine version in your order.
What are its dimensions and weight?
The listed dimensions are 110 × 58 × 58 cm and weight is 157 kg.
How do I request a quotation or spare parts?
Send the model, cable or load details, required configuration, quantity and destination. For parts, include the machine identification and component photos.
