Product Overview
The Winch TorqueMaster No. 3 featuring a robust green base with twin drums and top-mounted motor. Designed for demanding cable operations, it delivers 30KN pulling force with precision speed control, making it ideal for power line and telecommunication projects.
Technical Parameter
| Model | Winch TorqueMaster No. 3 |
| Traction Force | 30KN (max) |
| Power | 7.5KW copper-core motor |
| Speed Range | 0-20m/min (stepless adjustment) |
| Force-Speed Profile | 30KN at 12.7m/min / 25KN at 16m/min / 20KN at 20m/min |
| Dimensions | 135×74×37cm |
| Weight | 345kg |
Features & Advantages
Core Features
Dual-Drum Design
Enhanced cable handling capacity
Electromagnetic Brake
Instant stop safety system
Synchronous Control
Coordinates with rear-line equipment
Self-Tensioning System
Reduces manual labor
Heavy-Duty Construction
• Thickened wear-resistant drums
• Shock-proof shaft transmission
• Industrial-grade gearbox
Technical Advantages
High-Efficiency Motor
Copper-core for stable 30KN performance
Precision Speed Control
Full 0-20m/min range
Durable Transmission
Anti-vibration design prevents slippage
Low Maintenance
Reinforced components for long service life
Applications
- Power transmission line construction
- Telecommunication cable deployment
- Industrial cable pulling operations







Winch TorqueMaster No. 3: FAQ
What is TorqueMaster No.3’s maximum force?
The listed maximum traction force is 30kN.
How does force vary with speed?
The table lists 30kN at 12.7 m/min, 25kN at 16 m/min and 20kN at 20 m/min. Select against the required force-speed combination.
What are the motor and weight specifications?
The motor is 7.5kW and the listed machine weight is 345 kg.
How do I request a quotation or spare parts?
Send the model, cable or load details, required configuration, quantity and destination. For parts, include the machine identification and component photos.
