Product Overview
The Jiangniu 3 is a gasoline-powered cable conveyor featuring a compact green body with integrated control panel and wireless remote. Designed for versatile field applications, it combines robust performance with exceptional mobility.
Technical Parameter
| Model | Jiangniu 3 |
| Power System | Gasoline generator (electric + manual dual-start) |
| Motor Power | 1800W |
| Speed Control | 4-gear + stepless speed regulation (4-26m/min) |
| Optimal Speed | 10-16m/min (Gear 2 & 3) |
| Max Pulling Force | 4800N |
| Cable Diameter | 1-18cm |
| Dimensions | 90.5×65×65cm |
| Weight | 131kg |
Features & Advantages
Advanced Features
Dual Control System
Panel + wireless remote operation
Multi-Machine Synchronization
Built-in joint control module
Flexible Power Options
Optional inverter (for tool power) & transformer (silent operation)
Durable Components
Reinforced wear-resistant rubber blocks
Portable Design
Compact and lightweight for easy transport
Technical Advantages
Field-Ready Performance
Gasoline power eliminates grid dependency
Precision Control
Instant start/stop with push-pull mode switching
Adaptive Operation
Suitable for various working conditions
Team Coordination
Multiple units can work in sync
Typical Applications
- Remote power line construction
- Telecommunication network deployment
- Emergency cable repairs
- Industrial maintenance projects
Important Notes
- Parameters may vary depending on cable conditions (e.g., slippage) and environment
- Product appearance may differ slightly from images
- Optional accessories sold separately
