Product Overview
The Power Arrow 8 is an industrial-grade electric motor grinder featuring a blue motor unit with green base. Engineered for extreme cable operations, it delivers 80KN pulling force – the strongest in its class – with intelligent stepless speed control, making it ideal for ultra-high-voltage power transmission and large-scale infrastructure projects.
Technical Parameter
| Model | Power Arrow 8 |
| Max Pulling Force | 80KN (industry-leading) |
| Speed Range | 0-20m/min (stepless adjustment) |
| Power | 11KW premium copper-core motor |
| Power Supply | AC380V |
| Control Methods | Control panel + wireless remote |
| Safety Feature | Instant power-off braking |
| Dimensions | 125×75×55cm |
| Weight | 550kg |
Features & Advantages
Core Features
4-Speed Stepless Control
Instant start/stop operation
Dual Control System
Panel operation + 50m remote control
Industrial Safety
Automatic brake activation during power failure
Heavy-Duty Build
• 30mm thickened wear-resistant drum
• Anti-vibration shaft transmission
• Military-grade gearbox
Technical Advantages
Copper-Core Motor
Unmatched 80KN pulling performance
Heat/Slip Prevention
95% power transfer efficiency
Wide Speed Spectrum
Precise 0-20m/min control
Zero-Jam Guarantee
Tested over 10,000 cycles
Applications
- Ultra-high-voltage (500kV+) power lines
- Cross-country telecommunication deployment
- Offshore wind farm cable installations
- Mega infrastructure projects
Laboratory Test Notes
- Parameters may vary due to: Extreme environmental conditions (±15%); Cable slippage factors; Operational methodology
- Annual gearbox maintenance required
