Product Overview
The Bull NO.5 Cable Conveyor is a green, compact cable conveyor featuring dual control methods (panel + remote) and advanced speed adjustment. Designed for versatile applications, it combines portability with professional-grade performance in cable installation projects.
Technical Parameter
| Model | Bull NO.5 Cable Conveyor |
| Power Supply | diesel generator |
| Motor | 1800W |
| Control Methods | Panel + wireless remote |
| Speed Adjustment | 4-gear + stepless speed control |
| Optimal Speed | 10-16m/min (Gear 2 & 3) |
| Max Pulling Force | 4800N |
| Cable Diameter | 1-18cm |
| Conveyor Type | Track system |
| Dimensions | 90×67×66cm |
| Weight | 138kg |
Features & Advantages
Core Features
Dual Control System
Panel operation + remote control
Precision Speed Control
4-gear with stepless adjustment
Multi-Unit Synchronization
Built-in joint control module
Compact & Lightweight
Easy to transport (138kg)
Durable Track System
Wear-resistant rubber blocks prevent slippage
Technical Advantages
Instant Start/Stop
Push-pull switching for immediate operation
Flexible Speed Range
Full control from 4-20m/min
Reliable Performance
Copper-core motor ensures 4800N pulling force
Wide Compatibility
Handles various cable types (1-18cm)
Typical Applications
- Telecommunication cable deployment
- Power distribution system maintenance
- Confined space installations
- Industrial facility projects







Bull NO.5 Cable Conveyor: FAQ
How is Bull No.5 powered?
A diesel generator supplies the 1800W motor configuration. Confirm the supplied generator and electrical arrangement.
Which cable sizes and force are listed?
The cable diameter range is 1–18 cm and maximum pulling force is 4800N.
How is Bull No.5 controlled?
The model lists panel and wireless remote control, with four-gear and stepless speed adjustment.
How do I request a quotation or spare parts?
Send the model, cable or load details, required configuration, quantity and destination. For parts, include the machine identification and component photos.
Bull No.5 Selection and Configuration
Send cable specifications, site access details, route layout and the intended power arrangement. The listed dimensions are 90 × 67 × 66 cm and the weight is 138 kg.
Which cable sizes are listed for the Bull No.5?
The published table lists 1–18 cm cable diameter and 4800N maximum pulling force. Confirm suitability using cable weight, construction and route resistance.
What power configuration does the Bull No.5 use?
The power supply is listed as a diesel generator with a 1800W motor. Confirm the supplied generator configuration and site ventilation requirements.
What controls and speed are listed for this model?
Four gears and stepless speed adjustment are listed. The table gives 10–16 m/min in gears 2 and 3 as an optimal-speed reference; it does not specify a full speed range.
Request a Bull No.5 Quote
Send cable diameter, weight per metre, route length, bends, power availability, quantity and delivery destination. Request a quote on WhatsApp or send your project enquiry. Include the model name so we can discuss its configuration.
Compare cable conveyors and cable pushers and review our equipment selection checklist.
