Product Overview
This 8T diesel winch is a robust and reliable piece of equipment designed for heavy – duty pulling and lifting tasks. Manufactured by keepapexpower, it combines high – performance capabilities with user – friendly features, making it suitable for a wide range of applications, especially in mountainous and field construction environments.
Technical Parameter
| Model | 8T Diesel Winch (Shaft – driven) |
| Rated Pulling Force | 80KN |
| Overall Dimensions | 122 * 56 * 60 cm |
| Product Weight | Approximately 180 kg |
Performance Parameters
The winch is available with optional gasoline or diesel power, providing flexibility for different working conditions. The diesel – powered version offers high torque and long – lasting performance, ideal for continuous operation in remote areas.
Pulling Force and Speed at Different Gears
Forward Gear 1: The maximum pulling force reaches 80KN, with a pulling speed of 4.5 m/min. This gear is suitable for heavy – load pulling tasks that require high force.
Forward Gear 2: It provides a pulling force of 50KN at a speed of 8.5 m/min, offering a balance between force and speed for medium – load operations.
Forward Gear 3: With a maximum pulling force of 28KN, it can pull at a relatively fast speed of 15 m/min, which is convenient for lighter – load and faster – paced tasks.
Forward Gear 4: The pulling force is 15KN, and the speed is 28 m/min, enabling quick movement of light loads.
Reverse Gear 1: The pulling speed is 9 m/min, allowing for easy reversal of the load without significant pulling force.
Reverse Gear 2: It has a pulling speed of 11 m/min, providing more flexibility in reverse operations.
Features & Application
Structural Features
Multi – gear Adjustment
The multi – gear design allows for easy and quick adjustment according to different work requirements. Whether it is a heavy – load or light – load task, you can select the appropriate gear to achieve the best working efficiency.
High – strength Coupling
Equipped with a high – strength coupling, the winch ensures more reliable power transmission. This design reduces the risk of mechanical failure during operation and enhances the overall stability and safety of the equipment.
Robust Construction
The winch is built with high – quality materials and advanced manufacturing processes. Its sturdy frame can withstand harsh working conditions, ensuring long – term and reliable operation.
Application Scenarios
This 8T diesel winch is widely used in various fields, including but not limited to:
Mountainous and Field Construction
Its powerful performance and adaptability to different terrains make it an ideal choice for construction projects in mountainous and remote areas, such as cable laying, pole installation, and material transportation.
Utility Installation
It can be used for the installation and maintenance of power lines, communication cables, etc., facilitating the pulling and positioning of cables over long distances.







8 Ton Diesel Winch: FAQ
What is the rated pulling force?
The 8 Ton Diesel Winch lists 80kN rated pulling force.
What space and handling arrangements are needed?
Its listed dimensions are 122 × 56 × 60 cm and weight is approximately 180 kg. Check site access and handling arrangements.
Which operating details should I confirm?
Request the diesel engine configuration, rope requirements, anchoring instructions and model-specific braking procedure.
How do I request a quotation or spare parts?
Send the model, cable or load details, required configuration, quantity and destination. For parts, include the machine identification and component photos.
