Product Overview
The Apex No.3 is a wheeled optical cable tractor featuring a vibrant green body with distinctive orange-rimmed wheels and ergonomic push handle. Designed for telecom field operations, it combines gasoline-powered performance with dual-start convenience for reliable cable deployment.
Technical Parameter
| Model | Apex No.3 |
| Power System | Gasoline engine |
| Starting Modes | Electric + manual pull-start |
| Control Method | 4-gear manual shifting |
| Pulling Force | 3000N |
| Transmission | Reinforced crawler belt |
| Speed Range | 0-80m/min (4 adjustable gears) |
| Clamping System | Quick-release mechanism |
| Max Cable Capacity | 4-288 core fibers |
| Track Opening | 4cm maximum |
| Dimensions | 101×79.4×80cm |
| Weight | 109kg |
Features & Advantages
Core Features
Dual-Start System
Electric ignition with manual backup
Precision Speed Control
Four distinct gear settings
Cable Protection
Non-damaging crawler belt design
Ergonomic Handling
Push-bar for easy maneuvering
Fuel-Efficient
Optimized gasoline consumption
Technical Advantages
High-Torque Performance
3000N pulling capacity
Versatile Speed Adjustment
Broad 0-80m/min range
Quick Deployment
Instant start capability
Compact Mobility
Lightweight 109kg design
Applications
- Telecom fiber optic installations
- Long-haul cable pulling projects
- Underground conduit work
- Field maintenance operations







Apex No.3 Optical Cable Tractor: FAQ
How is Apex No.3 started?
The gasoline version lists both electric and manual pull-start modes.
How is speed controlled?
No.3 uses manual four-gear shifting, with a listed 0–80 m/min speed range.
What cable opening and force are listed?
Maximum track opening is 4 cm and pulling force is 3000N. Check the cable outside diameter and handling limits.
How do I request a quotation or spare parts?
Send the model, cable or load details, required configuration, quantity and destination. For parts, include the machine identification and component photos.
