Product Overview
The Apex No.5 is a gasoline-powered optical cable tractor featuring a vibrant green body with red-rimmed wheels and ergonomic push handle. Designed for telecom field operations, it delivers 4200N pulling force with intelligent control options for efficient cable installation.
Technical Parameter
| Model | Apex No.5 |
| Power System | Gasoline generator |
| Starting Method | Hand-pull start |
| Motor Power | 1200W |
| Pulling Force | 4200N (max) |
| Control Method | Panel button control |
| Transmission | Reinforced crawler belt |
| Speed Range | 0-80m/min |
| Speed Adjustment | 4-gear + stepless |
| Clamping System | Quick-release mechanism |
| Max Cable Opening | 5cm |
| Cable Compatibility | 4-288 core fibers |
| Dimensions | 103×79.4×80cm |
| Weight | 109kg |
Features & Advantages
Core Features
Dual-Speed Control
4-gear + stepless precision
One-Touch Operation
Push-pull mode switching
Cable Protection
Non-damaging reinforced crawler
Portable Design
Lightweight 109kg construction
Optional Accessories
• Inverter (tools power supply)
• Transformer (silent operation)
Technical Advantages
High-Efficiency Engine
4200N pulling capacity
Instant Start/Stop
Immediate response control
Wide Speed Range
0-80m/min adjustable
Versatile Application
Adapts to multiple scenarios







Applications
- Long-distance fiber optic deployments
- Underground conduit installations
- Telecom maintenance projects
- Remote area cable pulling
Apex No.5 Optical Cable Tractor: FAQ
Which cables are listed for Apex No.5?
The maximum opening is 5 cm and the stated compatibility is 4–288-core fiber cables. Confirm actual cable diameter and construction.
How is the machine powered and started?
It lists a gasoline generator, hand-pull start and a 1200W motor.
What controls and force are listed?
No.5 lists panel-button control, a 0–80 m/min speed range and 4200N maximum pulling force.
How do I request a quotation or spare parts?
Send the model, cable or load details, required configuration, quantity and destination. For parts, include the machine identification and component photos.
