TerraForce 600 PLUS Cable Conveyor

Model
TerraForce 600 PLUS Cable Conveyor
Motor Power
1500W
Net Weight
71kg
Technology Innovating Smarter Cable Solutions

    Product Overview

    The TerraForce 600 PLUS is a compact yet powerful cable conveyor featuring a distinctive green body with intuitive front control panel. Designed for efficient cable installation, it combines robust performance with exceptional portability.

    Technical Parameter

    Power Supply AC380V
    Motor Power1500W
    Max Pulling Force3400N
    Cable Diameter 1-10cm
    Conveying Speed4-26m/min
    Optimal Speed 6-10m/min (2nd gear 3rd gear)
    Dimensions 74×47×56cm
    Net Weight 71kg

    Features & Advantages

    Typical Applications

    • Indoor cable installation projects
    • Telecommunication network deployment
    • Power distribution system construction
    • Industrial facility maintenance
    01
    02
    03
    04
    05
    06
    07

    TerraForce 600 PLUS Cable Conveyor: FAQ

    What supply does TerraForce 600 PLUS need?

    The parameter table lists AC380V and a 1500W motor.

    Which cable sizes and force are listed?

    The cable diameter range is 1–10 cm and maximum pulling force is 3400N.

    What conveying speed and weight are listed?

    The conveying range is 4–26 m/min and net weight is 71 kg.

    How do I request a quotation or spare parts?

    Send the model, cable or load details, required configuration, quantity and destination. For parts, include the machine identification and component photos.

    Request this model’s configuration and quote

    TerraForce 600 PLUS Selection and Configuration

    Its listed dimensions are 74 × 47 × 56 cm and its net weight is 71 kg. Include cable specifications, bends, working clearance and destination in the enquiry.

    Which cable sizes are listed for the TerraForce 600 PLUS?

    The table lists 1–10 cm cable diameter and 3400N maximum pulling force. Confirm cable weight, construction and route conditions when comparing models.

    What power configuration does the TerraForce 600 PLUS use?

    The published supply is AC380V and the motor power is 1500W. Request confirmation of the supplied controls and electrical requirements.

    What controls and speed are listed for this model?

    The listed speed range is 4–26 m/min. The table gives 6–10 m/min in gears 2 and 3 as an optimal-speed reference; use the supplied operating instructions for setup.

    Request a TerraForce 600 PLUS Quote

    Send cable diameter, weight per metre, route length, bends, power availability, quantity and delivery destination. Request a quote on WhatsApp or send your project enquiry. Include the model name so we can discuss its configuration.

    Compare cable conveyors and cable pushers and review our equipment selection checklist.

    Specify the TerraForce 600 PLUS Control Package

    This model lists panel operation, remote control and a built-in joint control module. For a multi-machine order, send the model and controller details of every unit you intend to connect.

    • Confirm compatible machine versions and the number of units in the proposed group.
    • Specify the operator position, connection distances and required control cable lengths.
    • Request a connection drawing, an included-accessories list and the supplied operating instructions.
    • Agree a demonstration of group commands and stopping responses for the ordered configuration.

    Review the remote and multi-machine control checklist, then request a TerraForce 600 PLUS control-package quotation. Compatibility with other models and controller versions needs confirmation before ordering.

    Plan Site Access and Support for TerraForce 600 PLUS

    The published machine dimensions are 74 × 47 × 56 cm and the net weight is 71 kg. Measure the full access route, lifting arrangements and working position; allow room for the delivered controller, cable entry, supports and operator access rather than checking the machine footprint alone.

    • Request the delivered assembly dimensions, mass and approved lifting and anchoring instructions before planning handling.
    • Have the responsible site engineer check floor or platform capacity and the support arrangement for the actual installation loads.
    • Confirm supply frequency, phase configuration, duty rating and permitted operating environment with the supplier; AC380V and 1500W alone do not establish suitability for a tunnel or enclosed space.

    For route planning, use the substation and utility tunnel installation checklist. For abnormal heating, stop safely and follow the overheating symptoms and support-record guide; electrical testing and repairs require qualified personnel.

    What should I send for technical support?

    Send the machine identification and nameplate photos, controller version, operating duration, cable and route details, alarm messages and photos of the installed position. Include qualified electrical test results only when safely obtained under the approved procedure. Request configuration confirmation or TerraForce 600 PLUS support.
